Model No.

Voltage

Max load current

Max flow rate

Max static head

Power consumption

V（dc）

A

L/H

M

w

DC30A-1230

12

0.35

240

3.0

4.20

NOTE

l Information including continuous working time, working temperature and medium is required to be pre-confirmed with professionals; pump cannot work with high temperature or corrosive fluids.

l When pump is connected into circulation system, load current will be reduced to 70~85% of Max working current (opening outlet current).

l The head means the Max vertical lifting height of water,the flow is 0L/MIN@max head.

l The max flow rate means flow rate with no lifting height(according to the curve bellow)
