Brand:protech
Model:PT-T 1200
MOQ:-0 -
Send Inquiry
Description：1200℃ three zones tube furnace is mainly used for preparation of rare earth, electronic lighting,crystal annealing,biological ceramics,electronic ceramics, special alloy, magnetic materials, precision casting,vacuum sintering of metal heat treatment and other industries, protective atmosphere sintering, vacuum coating, CVD experimental measurement,material composition, etc
• Max heating rate: 20℃/Min
• Chamber size：220+440+220(mm)
• Controller：PID
• Power：5KW
Technical parameters
| Display | LED |
| Limiting temperature | 1200℃ |
| Working temperature | ≤1150℃ |
| Heating rate | Suggestion 0~20℃/min |
| Temperature zone | Three |
| Temperature accuracy | ±1℃ |
| Chamber size | Φ60×1400（mm） |
| Heated length | 220+440+220mm |
| Length constant temperature （?T=3℃) | 100+200+100mm |
| Heating element | Aludirome |
| Thermal couple | K Type |
| Rated power | 5 KW |
| Working voltage | AC 110V-480V 50/60 Hz |
| Temperature Control | PID automatic control via SCR power control |
| Heating curves | 30 steps programmable |
| Preset curve | 1 |
| Chamber material | Alumina Fiber |
| Outside Size | 1060×470×610 mm |
| Warranty | 12 month (exclusive wearing part) |
