Brand:protech
Model:PT-1200D
MOQ:-0 -
Main technical specification
1. Intelligent touch screen control system
2.Assumes the circular alloy heating wire in the chamber of a stove or furnace type vertical alignment, make more uniform temperature field.
3.It can be equipped with computer software interface, through the computer PC monitoring and operation.
4.No discoloration heating elements,so that the product in sintering will not be polluted.
| 1 | Model | PT-I-1200 Dental Vacuum porcelain furnace |
| 2 | Chamber model | lift |
| 3 | Display | Touch Screen LCD |
| 4 | Limiting Temperature | 1200C |
| 5 | Usable Range | ≤1150C |
| 6 | Heating Rate | 0~150C/min |
| 7 | Vacuum | -97Kp |
| 8 | Accuracy | ±2C |
| 9 | Inside Chamber Size | Φ100×700mm |
| 10 | Heating Element | Aludirome |
| 11 | Thermocouple | K Type |
| 12 | Max. Power | 1.4KW |
| 13 | Working Voltage | AC 208V-240V single phase, 50/60 Hz |
| 14 | Temperature Control | PID automatic control via SCR power control |
| 15 | Heating curves | 50 steps programmable |
| 16 | Communication interface | Rs485 |
| 17 | Stored Procedure | 100 sintering curve |
| 18 | Warranty | One year limited warranty (Consumable parts such as heating elements are not covered by the warranty) |
We have professional engineers with rich experiences on thermal processing technology and application, please feel free to contact us if you have any requirement or questions,
we will be available to service you anytime!
