45mm DIN Achromatic Objective: 4X,10X,40X(S),100X(S,Oil);

Wide Field Plane-Scope Eyepiece: WF10X;

Articulated Free Binocular Head, Intepupillary Distance:55-75mm,

30ºInclined, 360ºRotatable

Built-in Digital Camera System, Resolution:1280(H)

*1024(V),1/2Chip, USB2.0 with Micro-image Process Software

Nosepiece:  Backward Quadruple Nosepiece

Double  Layers Mechanical Stage:130x140mm,Moving Range X-Y: 70x50mm

Ø2-Ø30mm Iris Diaphragm And Ø32 Filter with ABBE Condenser:N.A. 1.25

Coaxial Coarse And Fine Focusing Adjustable Mechansim: 20mm,

Precision:0.002mm

Built-in Adjustable Brightness Halogen Lamp 6V/20W and Kohlar

Illumination System
