Tiazhou iLOT water-driven Injector/genuine injector for 1pg/cng

1.Individual proofing workshop

 2.Experienced Inspector and Buyer Services

 3.Full line of test machinery for all critical parts

 4.ODM, OEM service

 5.Quick Response within 24 hours

Specification

Water-driven Injector
RateL 0.4%-4%
Working Pressure: 0.2-5 Kgs/CM3
Inlet/Outlet Dimension: 32/25mm
Net Weight: 1.7kgs
6PCS/CTN;

MEAS(CM):52*36*42

The water engine action:
The suction and proportioning unit is built from a piston connected to the water engine, from which it derives its movement. The piston moves within a cylinder with a non-return valve. The movement of the piston within the cylinder causes the water to be injected and the required liquid additive to be drawn through a pipe inserted into a container. It is possible to regulate the supply ratio between the additive and the water passing through the injector model.The drawn additive is transferred through a inlet bypass directly into the main water line, without contact with the water engine.
