The rock wool trapeziform strip cutting machine

When make the roof panel , the trapeziform rockwool strip is cut on trapeziform strip cutting machine and feed on the groove of sheet by manual.

Parameter:

Total power: about 6Kw

This machine could slit the rock wool slab which is 1200mm*600mm(length *width),30-50mm thickness. Its density is 100-150kg/m3.

There is only one specification of cutting on this machine. Specification could be decided according to customer’s demand.

The saw knife is Ф305-500.The circle speed is about 1400 turn/min.

The rock wool slab will feed into the machine by roller. The max speed is about 3.5m/min, speed could be adjusted.

Processing area is closed and sealed. There is 4 dust outlets with diameter 150mm is kept on machine.
