Introduction:

Slurry pump can be widely used in mines, electric power, metallurgy, coal, environmental protection and other industries transport slurry containing abrasive solid particles.Such as metallurgical mill pulp conveying, hydraulic ash thermal power plants, coal washery coal slurry and heavy media delivery, dredging river, river dredging, etc.In the chemical industry, also can carry some corrosive slurry containing crystallization.

Specification

Model: 1.5 Inch
Capacity(Q): 31-94m³/h
Head (H):34.3-85.8m
Speed (N):970-3200
NPSHr: 1.4-2.9
Effiency: 44.7
Allowable Max Power(KW): 15KW
Weight: 690kg
Inlet Dia.: 50mm
Outlet Dia.: 40mm
Allowable particle: 14mm
