Y series rock drilling machine/ rock drill /drilling rig
2016-10-01 21:46  Views:185
Price:500.00 USD/Sets
Brand:HW
Model:Y18
MOQ:1 Sets
Send Inquiry

Y series rock drilling machine/ rock drill /drilling rig



Y8、Y18、 Y19 、Y26 type hand held rock drill with advantages of small volume, light weight, less gas

 consumption.it can be dry drilling, also can undertake wet drilling.

Applicable to small mines, quarries and mountain road construction, water conservancy

 construction in surface engineering construction of blasting hole drilling vertical or

inclined down or the secondary blasting hole. It applied to surface drilling vertical

down, slope blasting hole,or secondary blasting hole of small mines, quarries, mountain

 road construction, water conservancy construction .





Mdoel

Y8

Y18

Y19

Y26

Weight

8 Kg

18 Kg

19 Kg

26Kg

Length

400 mm

550 mm

600 mm

650mm

Cylinder bore

32 mm

58 mm

65 mm

65 mm

Piston stroke

27 mm

45 mm

54 mm

70 mm

Working air pressure

0.4-0.63Mpa

0.4-0.63Mpa

0.4-0.63Mpa

0.4-0.63Mpa

Air tube bore

19mm

19mm

19mm

19mm

Water pipe bore

13mm

13mm

13mm

13mm

Shank specification

22*108mm

22*108mm

22*108mm

22*108mm
