Gas spring strut YS611
2016-10-02 02:58  Views:120
Price:1.80 USD/Pieces
Brand:YSWJ
Model:YS611
MOQ:100 Pieces
Send Inquiry

Product Description:

A、cylinder: seamless steel pipe20#, Φ 15*1mm.

B、piston rod: steel 45#, Φ 6mm.

C、piston: brassH62.

D、sealing parts: O-ring fluoro rubber.

E、end fittings: PA66.

F、gas: nitrogen.

G、aircraft hydraulic oil ( still work well below 58°).

H、Plastic end fittings can withstand a pulling force of 1200 lbs.







Features:

A、upward opening, two stay.

   stay 1:  up-opening to 30°,the door lift up by itself.

   stay 2:  the door slow down to full opening when the angle up to 80°。

B、closing:  down-closing to 50°,the door full close by itself.





Product Advantages:

A、Pass SGS test over 100,000times, attenuation less than 10% after 100,000cycles.

B、Finish: metallic paint, scratch resistance, NSS 8grade/48h.







Product Parameter:

A、Application: for all up-opening door, still work well between -50°~ 80°.

B、Installation conditions: Pls refer to the attached table below.

   a、different choice according to the door weight and door height.

   b、over 600cm * 400cm, paired using is the best.







Others(Packing and Services):



Package: 10pcs/inner box,100pcs/box,

N.W/G.W: 16.64kgs/18.502kgs

MEAS: 34.5cm * 33.2cm * 29.5cm,

Delivery Date: Normally in one month

Samples Preparation: samples can be sent in 3 working days (DHL 3-5days,UPS3-5days,Fedex/TNT 3-5days,EMS 7days reach destination )
