Product Description：

A、Material：plastic POM、ABS、PA66、Zinc alloy、ZnAI4、 cold-rolled steel Q235、resistance oil、spring steel 65Mn

B、Finish：black plastic，black electrophoretic, blue zinc-plated

Features：

A、Upward opening to 90°, the door can keep stay still, sliding smoothly along the slide track by pushing

B、Better for space-saving

C、Soft closing without slam

D、Compare with YS336-B cabinet inside smooth slide which conceals inside the cabinet

Product Advantages：

A、space-saving, soft closing.

B、Adjustment is achieved by turning the screw to choose the closing speed.

C、Application: for filling cabinet, top tank.

D、Cycles: pass SGS certification of 30000 cycles.

Product Parameters：

A、Door height 360-450mm

B、Type: light duty 3-5kgs, heavy duty 5-7kgs

C、Length of slide: 350mm

D、Cycles: 30,000times

E、Please refer to the illustration below

Others（Packing and Services）：

Package: 1set/inner box，10sets/box,

N.W/G.W: 11.3kgs/12.85kgs

MEAS: 39.2cm * 20.2cm * 32.5cm,

Delivery Date: Normally in one month

MOQ:  500sets

Samples Preparation: samples can be sent in 3 working days (DHL 3-5days，UPS3-5days，Fedex/TNT 3-5days，EMS 7days reach destinatination)
