Function
1.AH-OC controller has one photocell. This controller can let 3 Low-intensity Single Aviation Light with LED or incandescent lamp and 1 Low-intensity Double Aviation Light with LED or incandescent lamp work at night and close during the day automatically at the same time by photocell.
2.Controller has one switch converting between steady-burning mode and flash mode for Low-intensity Single Aviation Light with non-solar way.
3.This controller has fault alarm function and remote monitoring function. When One of four lights has fault, controller will display alarm state by relevant LED indicator light and output alarm signal to BTS by dry contact.

Main Parameter

1.Mode: AH-OC

2.Control capacity for Aviation Obstruction Lights: ≤6

3.Operating voltage: AC220V (Option other voltage, AC120V, DC48V, DC24V, etc)

4.Power consumption: 10W

5.Max load: 2KW

6.Overall size(mm): 290 by 260 by 90

7.Installation size(mm): 250 by 130 by M4

8.Enclosure material: die casting aluminum

9.Working way: at night or all day

10.Weight: 1.5Kg

11.Application lights: Low-intensity Single and Double Aviation Obstruction Light

12.Ambient temperature:-55℃~+70℃

13 Wind load: 80m/s

14.Protection standard: IP67
