Advantages
1. 1 to 4 Nautical Miles (Tc=0.74)
2. PC material with good impact protection strength, thermal stability, high transmittance.
3. Bird spike against bird drop.
4. International-advanced cold LED with low power consumption, high brightness and service life of light source reaching 100000hours.
5. LED based on obstruction light last 15 times longer than traditional light source,incandescent light.
6. about 96% less power than 116W incandescent light.
7. Major Maintenance Cost Saving,Surge protection device inside light.
8. Strong corrosion resistance, Shock and Vibrations protection and UV protection.
9. Dawn to Dusk operating:Built-in photocell can let light work automatically at night,closed during the day.
10. 3/4inches installation size and small volume especially being suitable for telecom and flag-pole installation way.
11. IP67 protection standard, Full sealing structure.

Function

This product is single light with Photocell.It can work at night automatically when ambient brightness is lower than 500cd/m2 and close during the day.Volume of this light is very small,so it is especially suitable for flag-pole installation way.

Scope of Application

AH-LS/P-1 LED Marine Lanterns is commonly used on both fixed and floating structures for Aids to Navigation.

Main Parameter

1.Mode:AH-LS/P-1
2.Standard:IALA
3.Light intensity:1cd(1nm),5cd(2nm),15cd(3nm),38cd(4nm)
4.Flash rate:Flashing mode or Steady-burning mode
5.Light Character: option 256 light characters
6.Light source:LED
7.Service life of LED:100,000hours
8.Operating voltage:DC12V
9.Power Consumption:1W
10.Overall Size(mm):136 by136 by 220
11.Installation Size:3/4inches
12.Weight:1Kg
13.Emitting Color:Yellow,Green,White and Red
14.Ambient Temperature:-55℃~+70℃
15.Wind load:80m/s
16.Protection Standard:IP67
