Features

·

Specifications

·Input voltage: AC110~240V±10V, 50/60Hz

·Power: 230W

·Light source: YODN MSD230 7R 200W Lamp, (Philips 7R 230W Lamp optional)

·Color temperature: 8000K, luminous flux: 7950lm(6meters), intensity of illumination: 58760lx(20meters)

·Ballast: electronic ballast

·Lifespan: 2000hrs

·Color wheel: 14 colors+ white, clockwise and counterclockwise two ways rotating

·Gobo wheel: 1 gobo wheel, with 17 fixed gobos+ white, clockwise and counterclockwise two ways rotating

·Prism: rotating 16 prism, clockwise and counterclockwise two ways rotating, moving effect, atomization function

·Lens: 3pcs high quality slices lens type lens groups

·Atomization effect: 0~100% adjustable atomization flare angle

·Aperture: seventh beam regulation adjust

·Focus: linear focus

·Dimmer/strobe: 0~100% linear dimmer and double stroboscopic, speed(0.5~14 seconds)

·Pan: 540degree, resolution 8bit/16bit, automatic adjust

·Tilt: 250degree, resolution 8bit/16bit, automatic adjust

·Beam angle: parallel beam angle 0~3.8degree

·Control mode: international standard DMX512

·DMX channel: 16CH/17CH

·Control panel: color display, touch screen and rotary panel optional

·Other functions: when mechanical closed light, the source power halve automatically

·IP rating: IP20

·Outline dimension: 345mm(arms width)*475mm(total height)*405(base width)mm

·N.W: 16kg
