575W Moving Head Gobo Light OT-S575

Technical Parameters

1. Voltage: AC110V-240V, 50-60Hz

2. Lamp Bulb: HMI 575W

3. Power: 750W

4. Color Wheel:  8 colors can be used for high-speed one-way rolling effect, really achieve colorful light synchronization broadcasting

5. Gobo Wheel:  8 beautiful and replaceable gobos (with a glass gobo +6 metal gobos + white light)

6. Control Signal: DMX512

7. Channel: 12CH

8. Display: 2 * 16 blue and white LCD display

9. Scanning Range: horizontal  530 °, vertical 280 °, smooth and sharp scanning movement

10. Dimmer / Strobe: mechanical linear dimming, 1-10 times / s high-speed strobe

11. Color Mixing: CMY, 0-100% CTO

12. Data Input / Output: 3-pin XLR

13. Prism Effect: 3 facet prism, rotating prism effect

14. Focus: using electronic automatic focusing, near uniform clear gobo

15.Control System:  closed-loop control system, beam accurate positioning without losing step

16. DMX512 signal visual display of the first address code

17. DMX512 signal output using optical isolation, safe and reliable communication

18. Features:

    (1) 4 convection cooling fan, heat well

    (2) Internal air duct design optimization, compliance with all safety standards

19. Protection: IP20

20. Size: 470 * 446 * 588mm

21. Weight: 37kg
