9 PCS LED Moving Head Matrix Light OT-JZ09Y

Technical Parameters

1. Voltage: AC110-260V, 50-60Hz

2. Light Source: 9 * 10W 4 in 1 OSRAM light beads

3. Rated Power: 500W

4. Life Span: 50000h, low power consumption

5. Color: 4 colors

6. DMX Channel: 14CH, 19CH, 46CH

7. Control Mode: DMX512 signal control, master/slave, sound, auto

8. Strobe: 1-25 times / s high speed strobe

9. Dimmer: 0-100% linear dimming

10. Display: LED LCD

11. Operation Speed: 8/16 bit

12. Switching Effect: matrix beam head, single beam control

13. Beam Angle: 7 °

14.Scanning Range: 540 ° horizontal rotation, 270 ° vertical rotation, smooth, fast and accurate                                          horizontal / vertical rotation

15. Safety / Housing: high strength and heat-resistant engineering plastic housing, streamline                                            design

16. Function:

  (1) Scanning memory and error correction;

  (2) Built-in self-propelled program, easy to operate;

  (3) 1/16/48 three kinds of DMX control channels selectable;

  (4) 9 lamp beads can be individually controlled, intense beam effect

17. Motor: 2 pcs

18. Maximum Ambient Temperature: 40 ℃

19. Protection: IP20

20. Size: 270 * 150 * 400 mm

21. Net weight: 7kg             Gross Weight: 8kg
