Application:

◆Environment       Ambient temperature: -15℃～+40℃
                               Humidity ≤50%
                               Warranty: 3 years

◆Replace              Can directly replace T8 20W fluorescent lamp.

◆Site                     Indoor workshop,long working place or need more lamps place.

Outline:

Structure
                               PC shade:  Injection molding with milky PC of 94V0 fireproof level.

                               Inner with raidator: extruded 6063-T5 aluminum sections.

                               Lamp holder: Injection molding with porcelain white PC of 94V0 fireproof

                               level

Chip                       International or domestic famous chips less than 0.2W.

Protection             IP40

EMC and HI-pot:   EN60598-2008

Power Supply Parameter:

Feathers:

◆Using high power LED light source,higher luminous efficiency,more energy saving.

◆The interface is same with traditonal fluorescent lamps, can directly substitute.

◆Low voltage driving,safety,stability,reliability

◆Green environmental protection,the lamps doesn't contain lead,mercury and other harmful
    substance,no ultraviolet radiation.

◆All plastic shell avoid risk of shock.

Installation Diagram

1) Direct installation wiring diagram:
