Impact Crusher

Impact crusher is mainly used to crush many kinds of large, medium, small hard size materials with compression resistance no more than 350Mpa,in the fields of highway, reservoir, railway, airport and other fields that need rock with cubic shape. It features in high capacity, high performance, high reduction ratio, cubic shape and low flakiness.Special structure, connected without key, high chrome hammer, unique impact liner, deal with hard material, high efficiency and save energy, cubic shape of product, adjustable output size.

Impact crusher’s Performance and Features

1. The impact crusher is with unique simple structure, keyless connection.

2. Impact crusher is with high-chromium plating hammer and special impact liner plate.

3. The impact crusher is capable of highly efficient hard rock crushing while saving energy.

4. The final product of impact crusher is in the shape of a cube, the discharge grain size is adjustable to simplify the crushing circuit.

5. Easy maintenance, reliable performance.

Working principle of PF series impact crusher

When the impact crusher works, the motor drives the rotor rotate of the impact crusher with high speed, on the rotor where installed the hammers. When the materials get into the area where the hammers effect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being crushed again. The materials from large to small all to be crushed at the impact chamber repeatedly. The process won’t stop till the material are crushed to the required size and then discharged from outlet of the impact crusher.

Application of impact crusher

Impact crusher is mainly used to crush many kinds of large, medium, small materials whose side length is less than 500mm, and compression resistance should not be more than 350Mpa. Impact crusher are widely applied in many industries and working processes including highway construction, for building materials during construction, to break artificial rock, stone and sand, coal mines, chemical industry, hydroelectric industry, etc. Impact crusher owns the advantages of unique structure ,high chrome hammer and the special designed back block ,more suitable to crushing hard ore and energy saving with high efficiency ,the operation size is adjustabout ,simplity the crushing line ,what's more ,big crushing ratio with high effiency ,the finfished product with cubic forms and selective crushing.
