Brand:Believe Industry
Model:YX17-126
MOQ:1 Sets
Send Inquiry
Description:
The iron rolling shutter forming machine is used in manufacturing roller shutter door slats. The main elements of this equipment are decoiler, roll former, cutting device, product table, and control cabinet, etc.
| Technical Parameters - YX17-126 | |
|---|---|
| Raw Material | Carbon Steel, Galvanized Steel, Q235 |
| Material Thickness | 0.8-1.5mm |
| Material Width | Depend on specific profile |
| Diameter of Shaft | 76mm |
| Material of Shaft | 45# steel |
| Material of Rolls | 45# steel Chromed with thickness 0.05mm |
| Main Power | 7.5KW |
| Forming Speed | 15-20m/min |
| Forming Station | 14 stations |
| Cutting Type | Hydraulic cutting |
| Cutting Blade | Cr12 Mov |
