Description:
This down pipe forming machine is used in manufacturing rectangle or round down pipe with close entrance, and its specific dimension is made at customers' requirements. The main components of this device are decoiler, roll former, cutting device, control cabinet, and pipe bending machine, etc.
| Technical Parameters - Downpipe Roll Forming Machine | |
|---|---|
| Raw Material | Carbon Steel, Galvanized Steel, Q235 |
| Material Thickness | 0.4-1.0mm |
| Material Width | Depend on specific profile |
| Diameter of Shaft | 76mm |
| Material of Shaft | 45# steel |
| Material of Rolls | 45# steel Chromed with thickness 0.05mm |
| Main Power | 7.5KW |
| Forming Speed | 10-15m/min |
| Forming Station | 20 stations |
| Cutting Type | Hydraulic cutting |
| Cutting Blade | Cr12 Mov |
