Brand:Believe Industry
Model:Customized
MOQ:1 Sets
Send Inquiry
Description:
This double layer roll forming machine owns two independent forming moulds and it is suitable for producing metal roofing sheets and metal roof tile sheets. Main components of this machine are decoiler, guiding and leveling device, roll former, hydraulic cutting device, collecting table, hydraulic station, etc.
| Technical Parameters | |
|---|---|
| Raw Material | Carbon Steel, Galvanized Steel, Q235 |
| Material Thickness | 0.3-0.8mm |
| Material Width | Depend on specific profile |
| Diameter of Shaft | 76mm |
| Material of Shaft | 45# steel |
| Material of Rolls | 45# steel Chromed with thickness 0.05mm |
| Main Power | 3-7.5KW |
| Forming Speed | 15-20m/min |
| Forming Station | 12-24 stations |
| Cutting Type | Hydraulic cutting |
| Cutting Blade | Cr12 Mov |
