Brand:LION
Model:41x41 41x21
MOQ:1 Sets
Steel Channel Machine
| 1. Profile | 1. thickness 2.0mm 2. size 41x41 41x21 |
| 2. Process flow | Decoiling--feeding----forming---rotation straightening ---cutting---production |
| 3. Decoiler | Manual decoiler 1.coil inner diameter 450-700mm 2.coil max width 600mm 3.max carrying capacity 1500kg
|
| 4.Forming device | 1. Shaft material 45# steel adjustable treatment rollers material Cr12 2.Rollers 16main forming steps 3. Transport gear wheel 4. Forming speed 15-20m/min 5. Motor 5.5kw 6. size 5.0x1.0x1.2m
|
| 5. Cutting device | No burr saw cutting with air compressor |
| 6.Controlling device | 1. Displayer: text screen 2. PLC: control length and quantity Panasonic brand 3. Coder: ENC-1-1-1T-24 4. Automatic length and quantity measurement 5. Control voltage 24V 6. Unit of length: in millimeter(mm) 7.Manual and Automatic
|
| 7. Air compressor | air compressor |
| 8.Product stand | One set of product table:3m |
We are LION COMPANY from China. we are specialized in
1. light keel machines, like studs, track, angle, T-bar machines,
MAIN-T ( GEARS DRIVE ): USD10,500 FOB XINGANG, CHINA
( GEARBOX DRIVE ): USD12,600 FOB XINGANG, CHINA
CROSS_T ( GEARS DRIVE ): USD10,500 FOB XINGANG, CHINA
( GEARBOX DRIVE ): USD12,600 FOB XINGANG, CHINA
ANGLE ( GEARS DRIVE ): USD5,500 FOB XINGANG, CHINA
( GEARBOX DRIVE ): USD8,400 FOB XINGANG, CHINA
STUD&TRACK ( GEARS DRIVE ): USD13,000 FOB XINGANG, CHINA
( GEARBOX DRIVE ): USD18,000 FOB XINGANG, CHINA
FURRING ( GEARS DRIVE ): USD10,000 FOB XINGANG, CHINA
( GEARBOX DRIVE ): USD16,000 FOB XIGANG, CHINA
MAIN CHANNEL ( GEARS DRIVE ): USD7,000 FOB XINGANG, CHINA
( GEARBOX DRIVE ): USD11,000 FOB XINGANG, CHINA
ANGLE ( GEARS DRIVE ): USD5,500 FOB XINGANG, CHINA
( GEARBOX DRIVE ): USD8,400 FOB XINGANG, CHINA
2. roofing/wall panel machine, glazed tile machine, deck forming machine,
SINGLE LAYER MACHINE: USD24,500 FOB XINGANG, CHINA
GLAZED TILE MACHINE: USD30,500 FOB XINGANG, CHINA
DECK FORMING MACHINE: USD45,900 FOB XINGANG, CHINA
3. shutter door machine;
USD11,800 FOB XINGANG, CHINA
4. C/Z purlin machines,
C PURLIN MACHINE (1.5-3.0mm; 80-300mm ): USD28,000 FOB XINGANG, CHINA
Z PURLIN MACHINE (1.5-3.0mm; 100-300mm ): USD31,000 FOB XINGANG, CHINA
C/Z EXCHANGABLE MACHINE: USD44,000 FOB XINGANG, CHINA
5. guardrail machines, pipe forming and welding machines etc,
GUARDRAIL MACHINE ( TWO WAVES ): USD61,300 FOB XINGANG, CHINA
GUARDRAIL MACHINE ( THREE WAVES ): USD84,000 FOB XINGANG, CHINA
6. similar machines, also any other drawings requested by customers.
