Brand:Eagle pack
Model:-
MOQ:-0 -
Send Inquiry
| Size of the product to be wrapped | |
| Min load size(L XWxH) | 500 X 500 X 500 mm |
| Max load size(LXW) | 1200mmx1200mm |
| Max load height | 2400mm |
| Max weight | 2000kgs |
| Film Carriage | |
| Carriage | Mechanical brake film carriage Film tension adjustable |
| Machine Specification | |
| Turntable rotation speed: | 3-12 rpm adjustable |
| Turntable diameter | 1650mm |
| Turntable height | 78mm |
| Carriage Up/down speed | Adjustable |
| Power supply voltage | Standard 220 Volt 1 Ph - 50 Hz |
| Power | 1.2Kw |
| Packing efficiency | 20-40 loads/hour |
| Forklifting | Front & Rear |
| Machine size | 2675mm x 1650mm x 2860mm (LXWXH) Standard |
| Machine weight | 600kg |
| Stretch Film Roll detail | |
| Max. external diameter (D): | 230 mm |
| Internal diameter (d): | 76 mm |
| Film roll height (h): | 500 mm |
| Film thickness: | 17-35 µm
|
