Main technical parameters

Capacity: 100-125cups/hour (Stepless Speed Changing)

Total power: about 15KW

Power supply: 3P+N+PE -60/50Hz 380V (3-phase 5-line)

Compressed air consumption: about 1.0 M3/min,  pressure ≥ 0.6Mpa

Size: 10000mm×1200mm×2800mm (about)

Total weight: about 3000Kg

Diameters of Applicable Cups and Covers

Rim outer diameter of prefabricated cup:depend sample

Rim height of prefabricated cup: 80-120mm

Sealing film material: Aluminum-plastic or paper plastic Laminated  film

Sealing film depth: To Be Determined
