Brand:Kingon
Model:DY2000F-CS-B
MOQ:1 Sets
Send Inquiry
| Model | DY2000F-CS | |
| Wrap size | diameter | Ф（500-1500）mm |
| Breadth | 500-1600mm | |
| Machine size (L×W×H) | 3200×2000×2200mm | |
| Turntable diameter | φ2000 mm | |
| Turntable weight capacity (max) | 2000kg | |
| Turntable height | 460/530mm | |
| Power/voltage | 380VAC/50HZ/20A | |
| Total weight | 1080kg | |
| Wrap efficiency | 20-40 Pallets/Hour | |
| Turntable speed | 0-12rpm Adjustable turntable speed | |
| Film carriage | Power pre-Stretch system up to 350％ with adjustable speed | |
| Control system | PLC control，wrap layers adjustable | |
| Pneumatic ejection | Optional | |
| Top plate system | Motor-driven | |
| Pneumatic system | 0.6-0.8MPa , 1000ml/min | |
