Brand:Kingon
Model:DT1800FZ-PL/C
MOQ:1 Sets
| Model | DZ1800FZ-PL/C |
| Wrap size（L×W） | (800-1200)mm×(800-1100)mm |
| Wrap height(max) | L type：1800mm H type ：2400mm Y type：2800mm |
| Wrap efficiency | 30-50 Pallets/Hour |
| Turntable speed | 0-15rpm Adjustable turntable speed |
| Turntable size | Diameter：Φ1800mm Height：400mm |
| Turntable weight capacity (max) | 2000kg |
| Film carriage | Power pre-Stretch system up to 350％ with adjustable speed |
| Lift system | Lift speed adjustable |
| Top plate (optional） | Motor-driven |
| Cut & clamp unit | Pneumatic Control; Automatic Film Attaching, Cutting And Wiping |
| Control system | PLC control |
| Pneumatic | 0.6-0.8Mpa；1000ml/min |
| Total weight (max) | 1000kg |
| Machine size | 2820mm×1800mm×（2600-3200）mm |
| Power/voltage | Turntable 1.1kw Film carriage 0.35kw Lift system 0.37kw Conveyor 0.37kw (380V AC/50Hz/20A) |
