Model

DT1800FZ-PL/B

Wrap size(LX W)

(800-1200)mm X (800-1100)mm

Wrap height (max)

L type:1800mm   H type:2400mm   Y type:2800mm

Wrap efficiency

30-50 Pallets/hour

Turntable speed

0-15rpm  Adjustable turntable speed

Turntable size

Diameter:Φ1800mm  Height:300mm

Turntable weight capacity (max)

2000kg

Film carriage

Power pre-Stretch system up to 350% with adjustable speed

Lift system

Lift speed adjustable

Top plate (optional)

Motor-driven

Cut & clamp unit

Pneumatic Control, Automatic Film Attaching, Cutting And Wiping

Control system

PLC Control

Pneumatic system

0.6-0.8Mpa;1000ml/min

Total weight (max)

1000kg

Machine size

2820mm×1800mm×（2600-3200)mm

Power/voltage

Turntable 1.5kw  Film carriage0.35kw  Lift system0.37kw  conveyor system 0.37kw  (380V AC/50Hz/20A)
