Model

DT1650FM

Wrap size（L X W)

(500-1200)mm X (500-1200)mm

Wrap height(max)

L type：1800mm  H type：2400mm  Y type：2800mm

Wrap efficiency

20-40 Pallets/Hour

Turntable speed

0-12rpm Adjustable turntable speed

Turntable diameter

1650mm

Turntable height

98mm

Turntable weight capacity(max)

2000kg

Film carriage

Pre-Stretch film carriage,stretch up to 350% and adjustable speed

Lift system

Double chain structure,lift speed adjustable

Control system

PLC control,wrap layers adjustable,Turntable reposition automatically,photo-eyes auto-height sensing

Open turntable size

Custom made

Total weight(max)

700kg

Machine size

2745mmX1650mmX(2270-2870)mm

Power/voltage

Turntable:0.75kw  Film carriage:0.35kw  Lift system: 0.37kw/AC220V

Top plate(optional)

Motor-driven
