Aojie screw conveyor is mainly used in oil base driling mud transport and dry drilling cuttings transport. It contacted with decanter centrifuge and vertical cutting dryer.
The screw conveyor is designed 3 meters' long for each part, thus convenient for transporting. Below is the details.
Technical parameters
| Model | Trough Diameter | Screw length | Motor size | Transfer capacity | Rotation Speed |
| AJSC14-24 | 14 inch | 24 feet | 7.5 KW | 30 m3/h | 40/50/60 RPM |
| AJSC14-48 | 14 inch | 48 feet | 15 KW | 50 m3/h | 40/50/60 RPM |
| AJSC18-24 | 18 inch | 24 feet | 11 KW | 40 m3/h | 40/50/60 RPM |
| AJSC18-48 | 18 inch | 48 feet | 22 KW | 60 m3/h | 40/50/60 RPM |
