Introduction

Double roller briquette machine is a new designed machine for dry powder making into different kinds of balls.

Application

For double roller briquette machine, the raw material can be coal powder, charcoal powderm copper powder, iron powder, mineral powder, chrome ore powder, lead zinc ore, coke powder, slag, sludge, kaolin, bauxite refractory, nonferrous metal powder, refractory matter, ceramic filter sand etc. It can be used in metallurgical, chemical industry, coal and refractories industries etc.

Advantages and Structure

Double roller briquette machine has high forming rate, low power consumption, compact structure, easy maintenance and debugging obvious advantages, It is undoubtedly an ideal key equipment for pidgeon magnesium smelting process. To meet the requirements of the materials forming, preload screw using electromagnetic speed motor, speed control mode is manual type, the user can appropriately change the speed of the press machine according to the situation of the ball forming so as to achieve the highest balling rate and maximum capacity , suppression of material through the screening machine, sieve qualified pellets for packaging, undersized return to the storage mixed with the new materials and going to be pressed again.

Technical Parameters

Model: THHB-1000

Capacity: 30-40t/h

Roller Width: 650mm

Roller Dia: 1000mm

Power: 75-90kw

Spindle Speed: 10r/min

Main Shaft Bearing: 2097724*4mm

Ball Size: Customized
