Feature
Heavy duty speedy multi-functional 8-Head CNC Engraving Machine for processing 3D or complicate workpieces,360degree rotary for Stone,marble,white marble,granite,wood etc.For processing human body,buddha statue,sculpture,crafts and furnitures.
Technical Parameter
| Model Number | YZ3D-8-250-850 | ||
| Workpiece size | 250*850mm | ||
| Max load of the working table | 1400kg | ||
| Running mode | Servo drive | ||
| Machine size | 3000*1800*2200mm | ||
| Main spindle motor power | 2.2KW(8set) | ||
| Main spindle speed | 8000-24000r/min | ||
| Repeated positioning precision | 0.05mm | ||
| Max traveling speed | 20m/min | Max working speed | 15m/min |
| Total weight | about 2600kg | ||
| Power supply | AC380V±15% 50HZ | ||
