Brand:MINGDA
Model:Glitar 4C
MOQ:1 Sets
about us
Mingda Technology is one of leading companies that introduces 3D printing technology in China.
Corporatewith MIT and other worlds famous university ,mingda has the rich experience and advanced
technology in the 3d printer field.
Our R&D team was built up in the year 2010 , the first model Glitar1 was launched two years later in
2012 after the strict quality control , test and market survey. After years of sustained and rapid development, MINGDA has become a famous brand in 3D printer field.
Specification
| Layer thickness | 0.3mm |
| Structure | Full metal |
| AC Input | 95-265V, 50/60HZ |
| Standard nozzle diameter | 0.4mm |
| Printing speed | 0-200mm/s |
| Printing size | 300*200*200mm |
| Device dimension | 450*390*425mm |
| Print technology | FDM |
| Printing materials | ABS, HIPS, PLA |
| Filament diameter | 1.75mm |
| Hot Bed Temperature | 110 |
| Nozzles Temperature | 260 |
| Operating system | Windows , Linux , Mac OX |
| Hot Bed Material | Aluminum sheet |
| Positioning Precision | XY: 0.010mm Z: 0.002mm |
| File Types | STL, G-Code |
| Software Language | Chinese/English |
| Machine Power | 350W |
| Machine Weight | 26kg |
| Connectivity | USB, SD card |
Structure
1. High-end stainless steel body and LED light, a sense of fashion and technology.
2. Enclosed chamber, insulating temperature, reducing external interference and warp of print.
3. 10mm in thickness, high temperature resistant aviation aluminum plate, heating equally; with a high- strength support base to keep the plate stable and leveled; no need calibration,
easy to use.
4. Big build volume 300*200*200mm.
5.Fastened Z axis motor to make the layer thickness more precise, dual ball screw for Z axis on both
sides.
6. 1.75mm extruder, suitable for more material. (Nozzle temperature can reach 260 degree)
7. Cooling fan above nozzle, making the PLA filament cool faster reducing filament pending.
8. Multiple-choice 3D Printing material, like ABS/PLA /Nylon/Wood Filament. (We have tested before)
Support of MIngda Glitar Series 3D printers
If you have a technical problem or if your machine is misbehaving, please feel free to contact us as we have friendly support standing by to provide expert care to get you and your machine back on track.
We will do our best to get back to you as soon as possible and offer email service from Monday to Saturday. You will receive a response in 24 hours.
We also schedule phone support sessions as needed. Start a ticket with us, and if we can't resolve it quickly via email, we'll be happy to talk to you.
