Brand:LEDECNC
Model:-
MOQ:1 Sets
Performance characteristic
1) Used for milling the aluminum mullion/transom and reinforced mullion.
2) Large capacity milling,multi-pieces profile milling in one cycle.
3) Universal milling blades can be adjusted in up/down,left/right directions to fit or different processing requirement and ensure the efficient working.
4) Milling theend of for the reinforced mullion.
5) Large tools with high and stable milling speed for guarantee the working quality.
Technical parameter
| Power supply:380V 50Hz | Total power:8.8KW |
| Motor rev:2800r/min | Air pressure:0.5~0.8MPa |
| Diameter of main shaft:￠32mm | Diameter of milling cutter:￠250mm |
| Diameter of blade:￠300mm | Workable journey:0~1560mm |
| Workable dimension:530×320mm | Motor adjustable journey:0~85mm |
| Max processing tenoningsize:40mm | Dimension:3240×970×1670mm |
| Cutting surface roughness:12.5µm | Weight:750kg |
