CNC Rotary Table 5 axis

Characteristics:

The 5th axis can be synchronously operated with machine tools, also can be operating as double axis control with double axis controller in place.

High Accuracy

*Dual Lead Worm Gear System

*Increasing teeth-meshing ratio

*Adjustable backlash

*Rotary Table high accuracy retention

*Revolved portion of spindle taper adopt

*Rolling Cone Bearing ensure stable rotating center

*Minimum indexing degree 0.001 degree

*Application in spiral cutting, cutting tools manufacture, cam and aerospace industry

Heavy Duty Cutting Toleration

*Embrace system oil pressure retention device reduces unstable surface pressure and wobbling

*Heavy duty cutting toleration and high rigidity.

*Enclosed structure to block dust and cutting fluid

*Water-proof class IP65

Our single tooth worm wheel manufacturing techniques delivers high precision quality, outruns other conventional multi-toothed machine.

Material of the Worm Wheel: ALBC4 grade, HRB180 hardness, durable and postponing possible backlash occurrences.

Inspection:

Production is inspected by HEIDENHAIN automatic measuring device with report printing.
