Brand:katalor
Model:katalor-1
MOQ:2 Metric Ton
S45C is one of the high quality carbon structural steel under the standard of JIS G4501.
JIS G4051 Carbon steel for Machine Structural Use.
S45C steel equivalent material
GB 45#(Chinese standard), DIN 1.0503(Germany standard),NF C45(French standard),
UNI C45(Italy standard),NBN C45-1(Belgium standard), Ss1650(Sweden standard),
UNE F.114(Spanish standard), AISI/SAE 1045(America standard), ISO C45E4(International standard).
S45C material chemical composition
| Grade | C | Si | Mn | P | S |
| S45C | 0.42-0.48 | 0.15-0.35 | 0.30-0.9 | ≤0.03 | ≤0.035 |
JIS G 4051 S45C steel plate mechanical property
| Grade | Yield strength MPa | Tensile strength MPa | Elongation % | Impact energy | Hardness(HB) |
| S45C | ≥490 | ≥686 | ≥17 | ≥78 | 201-269 |
Because of its high strength and good mechanical property, S45C steel is widely used in various fields, especially in the machinery manufacturing. If yo need S45C material and want to know S45C steel specification, please contact us freely. We will provide you the competitive price and good quality.
