Brand:Unit Top
Model:Q43-4000
MOQ:1 Sets
Send Inquiry
Specifications
1, fluid drive system
2, smart design & solid structure
3, handy operation panel
4, various types 63-500T
5, customize service
Technical parameter:
| Max shear force | 4000 kn |
| Machine size: | 3200*1200*2200 mm |
| Shearing frequency (per/min): | 8-12 times/min |
| Max blade opening (mm): | 620 mm |
| Blade length: | 1200 mm |
| Operation: | Manual/Automatic |
| Power: | 22 KW |
| Nominal pressure: | 20 Mpa |
| Max sheared material size | Angle steel: 180*180*15 mm (3 pcs) |
| I-steel: 320*132*11.5 mm | |
| Channel steel: 320*90*10 mm | |
| Steel plate: 20*1000/30*600 mm | |
| Square steel: 80*80 mm | |
| Round steel: 90 mm |
