PPR water pipe making machine

INTRODUCTION:

Using a special screw design and enhanced plasticization effect of PP-r to ensure high-quality high-speed extrusion, high shear stress and low temperature to ensure that raw materials of high-performance plastics extrusion, the measurement on the feeder with the drying system to ensure that PP-r extrusion uniform.

SPEIFICATION:

Diameter  range of 20-160mm,

Maximum line speed up to: 10m/min

FEATURES OF THIS EXTRUSION LINE:

This extrusion line is consist of the single screw extruder, the vacuum calibration, the hualingoff machine, cutting machine and stacker

1) SINGLE SCREW EXTRUDER:

Screw adapts the bimetalic material with very good quality.

Model: LSJ65/30, LSJ90/30

2) SINGLE SCREW CO-EXTRUDER:

For extruding marking line

Model: SJ25/25, SJ30/25

3) GEARBOX REDUCER:

Hardening teeth/gear surface and low noise

Famous Brand made in Jiangxi Jiangyin

4) DIE HEAD DESIGN

Split spiral die head design

Specially designed for PPR .

Uniformed plasticization and high efficient extrusion.

5) VACCUM CLIBARTION TANK AND VACUUM WATER SPRAYING COOLING TANK

Material: high-degree excellent stainless steel

Has a very good cooling and forming effect.

6) SCRAPLESS CUTTING MACHINE

Adopts imported PLC control

High precision and accuracy

Can be length pre-setting

7) MAIN ELECTRICAL COMPONENTS:

Famous imported brands:Omron ,ABB, Schneider, Simens, Delix, RKC
