Type

45″

48″

51″

55″

63.5″

65″

Mould opening way(mm)

Horizon/turn

Horizon/turn

Horizon/turn

Horizon/turn

Horizon/turn

Horizon/turn

Center mechanism mode

B

B

B

B

B

B

Mould heating

Steam pot (heating plate)

Steam pot (heating plate)

Steam pot (heating plate)

Steam pot (heating plate)

Steam pot (heating plate)

Steam pot (heating plate)

Quantities of mould

2

2

2

2

2

2

Max. mould closing force (KN)

1600×2

1750×2

1750×2

2950×2

4220×2

4300×2

Mould height(mm)

190-430

191-445

191-445

245-445

254-635

254-635

Max.diameter of curing tire (bifid mould)

975

980

980

1098

1270

1270

Max.diameter of curing tire (segmented mould)

750

860

860

1016

1135

1135

Main motor power (KW)

11

16

16

13

13

16

Overall size

L x W x H (mm)

4120×4425 ×3100

4400×4355 ×3200

4400×4355 ×3200

4500×5950 ×4080

7000×5520 ×5950

7000×5670 ×5980

Weight(t)

32

35

35

48

60

63
