Type

RSL-600

RSL-800

RSL-900

Max. rubber sheet width (mm)

600

800

900

Thickness of the rubber sheet(mm)

4-10

4-10

6-12

Sheet temperature (for reference)

Ambient temperature +5ºC

Ambient temperature +5ºC

Ambient temperature +5ºC

Line speed of taking-in conveyer(m/min)

3-35

3-35

3-35

Piece rod chain speed (m/min)

0.117-1.17

0.117-1.17

0.117-1.17

Hanging height of
the sheet hanging
bar(mm)

1400

1400

1400

Swing sheet length -adjustable(m)

1.3

1.3

1.3

Swing sheet frequency(m/min)

13

13

13

Number of cooling fans (set)

12-16

20-32

24-32

Total power(KW)

16

20-26

25-35

Overall Dimension L x W x H (mm)

12500x2200x2800

15000x2200x2800

18000x2300x3000
