Brand:fucheng
Model:FCYJ-2.0E
MOQ:-0 -
Send Inquiry
Main Technical Parameters
| Motor Model: Y2-250-4 | Motor Power:60KW |
| Motor Voltage:380V | Torque Converter: C273.1-295 |
| Transmission System: RT20324-12 | Drive Axle Type: NO—SPIN |
| Braking System: Working Braking, Parking Brake | Bucket Capacity: 2 m3 |
| Max. Lifting Height: 3740mm | Min. Ground Clearance: 250mm |
| Total Weight: 12T | Climbing Ability: 16° |
| Max. Traction: 100KN | Max. Shovel Force: 80KN |
| Hydraulic Tank Capacity: 156L | Running Speed: 0-10km/h |
| Control Voltage: AC36V | Lighting Voltage: AC24V |
| Steering Angle: ±33° | Min. Turning Radius: 5200mm |
| Dimensions(Length* Width*Height)：7300 * 1500 * 2050 | |
