Brand:DHH
Model:-
MOQ:1 Sets
Send Inquiry
| DBF series (belt)variable frequency screw compressor technicalparameters | ||||||||||||||
| DHH | Air flow Capacity(m3/min)/cfm | Power | Noise | Outlet Diameter | Dimension | Weight | ||||||||
| 0.7Mpa | 0.8Mpa | 1.0Mpa | 1.3Mpa | KW/HP | DB(A) | INCH | W×D×H mm | Kg | ||||||
| MODEL | m3/min | cfm | m3/min | cfm | m3/min | cfm | m3/min | cfm | ||||||
| DBF-7.5A | 0.91 | 32.1 | 0.84 | 29.6 | 0.75 | 26.5 | 0.63 | 22.2 | 5.5/7.5 | 65 | G3/4'' | 780×680×800 | 320 | |
| DBF-10A | 1.3 | 45.9 | 1.2 | 42.4 | 1.0 | 35.3 | 0.84 | 29.6 | 7.5/10 | 65 | G3/4'' | 780×680×800 | 350 | |
| DBF-15A | 1.7 | 60 | 1.6 | 56.5 | 1.4 | 49.4 | 1.2 | 42.4 | 11/15 | 65 | G3/4'' | 1100×800×980 | 430 | |
| DBF-20A | 2.4 | 84.8 | 2.3 | 81.2 | 2.0 | 70.6 | 1.6 | 56.5 | 15/20 | 68 | G3/4'' | 1100×800×980 | 460 | |
| DBF-25A | 3.0 | 105.9 | 2.9 | 102.4 | 2.7 | 95.3 | 2.3 | 81.2 | 18.5/25 | 68 | G1'' | 1250×870×1180 | 620 | |
| DBF-30A | 3.7 | 130.7 | 3.6 | 127.1 | 3.2 | 113 | 2.8 | 98.9 | 22/30 | 68 | G1'' | 1250×870×1180 | 680 | |
| DBF-40A | 5.2 | 183.6 | 5.0 | 176.6 | 4.5 | 158.9 | 3.8 | 134.2 | 30/40 | 69 | G1'' | 1250×870×1180 | 790 | |
| DBF-50A | 6.5 | 229.5 | 6.2 | 219 | 5.6 | 197.8 | 4.9 | 173 | 37/50 | 69 | G11/2'' | 1540×950×1290 | 920 | |
| DBF-60A | 8.0 | 282.5 | 7.3 | 257.8 | 7.0 | 247.2 | 5.9 | 208.4 | 45/60 | 70 | G11/2'' | 1540×950×12900 | 1050 | |
| DBF-75A/W | 10.1 | 356.7 | 9.5 | 335.5 | 8.7 | 307.2 | 7.8 | 275.5 | 55/75 | 70 | G2'' | 1600×1150×1420 | 1580 |
