Brand:DHH
Model:-
MOQ:1 Sets
Send Inquiry
| DL Series Low Pressure Screw Compressor Technical Parameters | ||||||||
| DHH | Capacity | Power | Noise | Outlet Diameter | Dimension | Weight | ||
| MODEL | Mpa | m3/min | KW | HP | dB(A) | INCH | W×D×H mm | kg |
| DL3-30A | 0.3 | 6.5 | 22 | 30 | 65 | G11/2" | 1600×1000×1400 | 800 |
| DL3-50A | 10.0 | 37 | 50 | 65 | G2" | 2200×1200×1550 | 1400 | |
| DL3-100A | 20.0 | 75 | 100 | 72 | DN65 | 2400×1530×1600 | 2800 | |
| DL3-125A | 25.0 | 90 | 125 | 72 | DN65 | 2600×1550×1800 | 3200 | |
| DL3-175A | 32.0 | 132 | 175 | 75 | DN80 | 2800×1600×1850 | 3800 | |
| DL3-200A | 42.0 | 160 | 200 | 75 | DN100 | 3800×1800×1900 | 4500 | |
| DL4-100A | 0.4 | 19.0 | 75 | 100 | 72 | DN65 | 2400×1530×1600 | 2500 |
| DL4-125A | 22.0 | 90 | 125 | 72 | DN65 | 2600×1600×1700 | 2700 | |
| DL4-150A1 | 27.5 | 110 | 150 | 73 | DN80 | 2800×1750×1850 | 3200 | |
| DL4-150A2 | 30.0 | 110 | 150 | 73 | DN80 | 2800×1750×1850 | 3200 | |
| DL4-220A | 42.0 | 160 | 220 | 75 | DN100 | 3500×1900×1950 | 3800 | |
| DL4-300A | 59.0 | 220 | 300 | 78 | DN125 | 3500×1900×1951 | 5500 | |
| DL5-125A | 0.5 | 19.0 | 90 | 125 | 72 | DN65 | 2400×1530×1600 | 2500 |
| DL5-150A | 22.0 | 110 | 150 | 72 | DN65 | 2600×1600×1700 | 2700 | |
| DL5-175A1 | 27.5 | 132 | 175 | 73 | DN80 | 2800×1750×1850 | 3200 | |
| DL5-175A2 | 30.0 | 132 | 175 | 73 | DN80 | 2800×1750×1851 | 3200 | |
| DL5-250A | 42.0 | 185 | 250 | 75 | DN100 | 2800×1750×1852 | 3800 | |
| DL5-350A | 59.0 | 250 | 350 | 78 | DN125 | 2800×1750×1853 | 5500 |
