Full features Quilting Embroidery Control System, equipped with 10.4

Touch Screen Control Panel, user friendly window style display.

33 dual needles sewing heads, maximum 66 needles sewing at the

same time. In theory, maximum quilting embroidery width is

3600mm.

Each head works in small stitch sewing at minimum 50.8mm

(2 inches). base on production requirement, each needle of two can

be manually switch on or off individually, set the sewing stitch size to

50.8mm (2 inches), 101.6mm, 203.2mm accordingly, plus alternate

head lock function, realize ability to do complicated patterns

production.

Working speed 750-800 rpm.

Automatic thread breakage detection, shorten machine down time,

get the most production from running machine.

Equipped with jumbo rotary hook with larger thread holding capacity,

decrease bobbin replacement time, further increase production time.

Material loading and reverse movement is controlled by Y-direction

rollers, X-direction driving stud mechanical movement is driven by

servo motors. All driving stud, railway, and servo motors are using

same parts as our model RP424 Quilting Embroidery Machine
