Trim Width: 2400mm

Speed: 150-180 m/ min

Output: 50-120g/m2

Daily Capacity: 20 T/D

Track Gauge: 3400mm

Transmission mode: AP transmission Frequency control system, section drive and Digital closed-loop control system

Cylinder Section: Cylinder mould 1500mm * 2800mm, Couch Roll: 400mm * 3000mm, Back Roll: 650mm * 3000, Pneumatic pressure device, Pressure mould former

Press Section: Stone Roll: 650mm * 3000mm, Rubber Roll: 600mm * 3000mm, Pneumatic pressure device

Dryer Section: Dryer 2500mm * 2300mm, Dryer: 1500mm * 2300mm, Pneumatic corrector, Electric tensioning device, Carrier roller

Rewinding Section: Automatic rewinding machine 2400mm

Finishing section: Cutter
