Trim Width: 3200 mm

Output  Weight: 110-600 g/㎡

Daily Capacity: 45-55 T/D

Transmission speed: 280 m/min

Cycling speed: 400 m/min

Track Gauge: 3400 mm

Transmission mode: AC Frequency, section drive,

Cylinder section:  Cylinder mould: 1500mm * 2800mm (stainless steel), Couch Roll: 450mm * 3000mm, back Roll: 450mm * 3000, Pneumatic pressure device, Pressure mould former

Press section:    Stone Roll: 650mm * 3000mm, Rubber Roll: 600mm * 3000mm, Rubber Roll: 400mm * 3000mm

Dryer section:   Dryer: 2500mm * 2950mm, Dryer: 1500mm * 2950mm, Compression roll: 400mm *3000mm, Pneumatic pressure device, Rubber Roll: 600mm * 3000mm

Finishing Equipment  ：Cutter, Automatic Rewinding machine
