Output Weight: 100-250g/ m²

Daily Capacity : 30-35t/d

Tirm Width: 3200mm


Speed: 80-150m/min

Cylinder Mould: 3750mm

Track Gauge: 4300mm


Drive way: Alternating current frequency conversion ,section drive

The main Section :
    Cylinder Section: Cylinder Mould :1500 mm×3750mm, Couch Roll :500×3750mm  Rubber Hardness Shore 38°C±2

    Press Section: Marble Roller 800 mm×3750mm, Rubber Roll 750 mm×3750mm,Rubber Hardness Shore 90°C±2,Pneumatic Pressure Device.

    Dry Sction: Dryer 2500mmx3750mm and 500mm×3750mm , Roller 750 mm×3750mm, Rubber Hardness Shore 90°C±2, Pneumatic Pressure Device, Opposite Pressurized Roll , Rubber Hardness shore 90°C±2,
