ZHUMADIAN DALI TIANJUN SPECIAL VEHICLE MANUFACTURING CO.,LTD

All the semi trailer types can be customized according to your country requirements and local conditions

Tare Weight:8-13T

Dimension:12000mm-18000mm*2500mm-3500mm*3050mm

Please indicate the working platform height and length.

Payload (T):30T-60T

Axle:8-13T, FUWA / BPW

Rim:6.5-20   7.5-20   8.00-20   8.5-20

Tire:8.25R20   10.00R20    11.00R20    12.00R20

Suspension system:Mechanical or Air

Spring leaf:90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12mm

King pin:JOST brand 2.0(50mm) or 3.5(90mm)inch Bolts type or Welding type

Support leg:JOST brand D200T or China brand 28Tons (Double speed)

Main beam:T610/700 High strength steel for Light vehicle series

                     Q345 Steel for Heavy vehicle series

Side beam:T100/140/160/180 High strength steel for Light vehicle series.

                     Q235/345 Steel for Heavy vehicle series

Gooseneck:According to the vehicle high

ABS: Anti-lock braking system

Twist Locks:Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type)

Light:LED light

Electrical system:24v & 7 ways socket

Tool box:

One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)

Painting:

Complete chassis sand blasting to clean rust,1 coat of anticorrosive paint prime,2 coats of final paint.

Shipping Terms:By bulk cargo carrier, RORO or LCL Container.
