Feature

This machine is a multi-axis CNC intersecting line cutting system, it can cut tubes of various complex intersection form in Ocean engineering and steel structure cutting.

• 1. With the original cutting mode of fixed pipe and equipment rotation, we successfully, avoid cutting defects caused by pipe of non-standard, achieve high cutting precision.
• 2. No cutting zone, saving in material , infinitized by length and weight of pipe etc make it especially suitable for super long and super heavy tube and tube with fixed length in Ocean engineering and Bridge.
• 3. Compact structure, handling without dismounting, the overall transport.
• 4. Can be used for square tube multi-pipe intersection and circular pipe small angle cutting.
• 5. Heavy duty–great choice.
• 6. Easy operation ensures fast
• 7. Turning roll and conveyor design evenly supports and centers pipe under cutting torches
• 8. One person performs all cutting and handling operations
• 9. Safe, efficient material handling uses variable speed
• 10. High precision and more stability
• 11. Auto Beveling, cutting any pipes.
• 12. Programming and flame/Plasma cutting both.
• 13. Easy to use programming software – no special skills required.
• 14. Large pre-loaded cut library

Application area

To be used to cut thick tube and pipe of carbon steel(flame),stainless steel, alloy steel, aluminum, and other metal materials, applied in areas including ship building, pressure vessel, aerospace, bridge construction, steel structure , electronic power and engineering machinery.

Technical parameters

Cutting Technical Specifications

• 1. Cutting steel, pipe or tube
• 2. Cut forms: intersecting line of the expanded variety of graphics, With Groove
• 3. Control axis: 246 shafts, bevel cutting standard 5-axis
• 4. Cutting diameter: according to customer requirements
• 5. Cutting mode: plasma or flame
• 6. The maximum length of pipe: less than 12m
• 7. Pipe clamp method: chuck
• 8. Power Drive: precision AC servo and special planetary gear
• 9. Control system: dedicated for intersecting line cutting system can control 5 axes (quantitative)
• 10. Set intersecting line cutting vision library

Cutting Sample

Packages

Canton Fair

Foreign customers

Our company

Our Workplace

After-sales service

• 1. We will offer some of the parts for free in the first year. The buyer needs to pay for the shipping cost for the parts. The user needs to send us pictures of the broken one, then we will send out the part they need. The whole machine we offer one year guarantee time free, without consumable parts replacement and man-made fault.
• 2. In the first year, if the buyer needs our engineers to come to the local to fix some problems of the machine that they cannot fix by themselves; we will send our engineers for free. The buyer needs to pay the flights, housing and meals for the engineers in the local.
• 3. We will offer our service through email and phones if the buyer needs any help on technical problems.
• 4. My company English software can do all kinds of pattern recognition, software upgrading and updating free.

Why choose us?

• 1. Canadian Professionaloptimize CNC system has , AutoCAD version of the project design can be directly generated CNC machine code . Dimensional simulation operation, the node is expanded , long tube splitting , fittings optimization , oversized EGES DXF SAT and STL and other software compatibility
• 2 A userfriendly design , casting parts precision machining equipment to ensure highprecision, high stability , high life expectancy.
• 3. One year warranty,free maintenance throughout service time.
