Specification:

Ÿ   Item no.: QL180-TS-2

Ÿ   Equipment: Fiber opener 1pcs; Fan 1pcs; double slot stuffer 2sets; Control screen 1pcs.

Ÿ   Dimension: 4600*4800*2400mm

Ÿ   Voltage: 380v 50Hz 3phase

Ÿ   Power: 12.85kw

Ÿ   Stuffing pipe diameter: 1.2-6cm * 4sets

Ÿ   Stuffing slot: 4 pcs

Ÿ   Labor: 5 person

Ÿ   Air pressure: 0.6-0.8Mpa, 1.2kg/m3

Ÿ   Control system: PLC controlling

Ÿ   Capacity: approx. 300kg/h

Ÿ   Weight: 1500kg

Description:

Ÿ   The computerized teddy bear stuffer is the highest technical for toy producing in China that the whole line is controlled by computerized system.

Ÿ   only 5 operators producing about the 300kg per hour can handle it.

Ÿ   The material application is 2 or 3 dimensional hollow siliconized polyester fiber that shorter than 100mm; the best material choice for bear producing is 32mm length and other spec. is the same.

Ÿ   High capacity and technology, reliable quality.

Ÿ   Please contact us to get the operation video for a reference.
