Brand:Judong
Model:-
MOQ:1 Sets
| Item | DLG-700 | DLG-900 | DLG-1100 | DLG-1200 |
| Max.width of porduct(mm) | 1200~1600 | 1200~1600 | 1400~2000 | 1400~2000 |
| Dia.of vulcanizing drum(mm) | 700 | 900 | 1100 | 1200 |
| Working width of drum (mm) | 1400~1800 | 1400~1800 | 1600~2200 | 1600~2200 |
| Total pulling force of pressure tape (t) | 38~49 | 49~62 | 84~116 | 92~126 |
| Linear speed of vulcanizing drum(m/min) | 0.04~1.12 | 0.05~1.42 | 0.06~1.8 | 0.07~1.95 |
| Steam pressure (Mpa) | 0.6 | 0.6 | ≤ 1.0 | ≤ 1.0 |
| Main motor puwer (kw) | 4~5.5 | 5.5~7.5 | 7.5~11 | 7.5~15 |
| Overall dimension (mm) | 8300×(4400~4830)×2100 | 8800×(4400~4830)×2350 | 10000×(4550~5150)×2800 | 10000×(4580~5180)×2800 |
| about werght (t) | 20~30 | 24~38 | 36~45 | 48~52 |
