Applicable Materials: Acrylic/ Plexiglas/double color board/ ABS board/ bamboo/ MDF/ wood /paper/ leather/ woolen/ rubber/ resin/ ceramic/ crystal/ glass/ marble/ granite etc.

 Applicable Industries: Advertisement(marks/ signs/ billboards/ plates)/bamboo & wood product/ art craft work/ ornament/ paper-cutting /cloth/ fabric/ handbag/ glove/ garment/ leather/ embroidery/ shoemaking/ toy/ crystal/ packing & printing/ panel/ mould/ decoration/upholster and other related industries.

Features:

• Precision mould casting, high rigidity and small accumulated error.
• Large power spindle cuts easily and quickly.
• High speed (curve and straight line shares same speed, and curve line is more smooth. ), high efficiency. Running speed is more than 14 m/min. And 1325M1530M can even reach to 35 m/min.
• Two motor-driver with distinctive double rack transmission, making it work steadily for a long time.
• Continue to engrave after point-break and bits/knife-breaking. Hold more than 9 points.
• Professional engraving software. Such as CorelDraw, Type3, Artcam, Castmate, Proe, Artcut and other CAD/CAM software.

Technical Specifications:

Model: BX-1325/1530/1325M/1530M

X/Y axis working area: 1300*2500/1500*30000mm

Z axis working area: 120mm

Platform Size: 1500*3100/1700*3600mm

Max. Working Speed: 14/35m/min

Max. Engraving Speed: 12/20m/min

Type of Clamp: Vacuum(1325M/1530M)

Interface: USB(1325M/1530M)

Resolution: 0.01/0.03mm

Repositioning Accuracy: 0.05mm

Max. Feeding Height: 200mm

Command: G Code*. U00*. Mmg*. Plt

Software Surroundings: Windows98/2000/XP

Power: AC220V or 380V/50Hz

Spindle Power: 1.5/2.2/3/4.5Kw

Spindle Speed: 0-24000rpm

Work Mode: Stepper

Accessories Chosen By Customer:

Large Power Spindle/ imported Spindle/ Multi Spindle/ DSP Handle With USB Interface/ Vacuum System/ Servo System etc.
